Infrastructure Specification Schedule

Infrastructure Specification Schedule

Project: Network Infrastructure & Power Distribution Upgrade

Standard: TIA-942 (Data Centers) / IEC 61439 (Low Voltage)

Safety Level: LSZH (Low Smoke Zero Halogen) – Mandatory for Indoor Use

Phase 1: Containment & Support (The Backbone)

Installation Priority: High. Must be completed before any cabling begins.
Item Specification Details Installation Notes Standards Ref
Cable Tray 300mm(W) x 60mm(H) x 1.6mm(T), Perforated Hot Dip Galvanized (HDG) min 50 microns. IEC 61537
Tray Fittings Horizontal Bends (90°), Tees, Risers (Inside/Outside) Radius must match tray width to prevent cable kink.
Support System 10mm GI Threaded Rods, Slotted C-Channels (41x41mm) Max span 1.5m. Use beam clamps for ceiling fixing.
PVC Ducting 100x100mm Slotted Trunking For vertical cable management inside racks/walls. UL 94V-0
Conduits 50mm Rigid PVC & 25/50mm Reinforced Flexible Flexible pipes for “final drop” to equipment only.
Fixing Accessories 10mm x 100mm Anchor Fasteners, GI Saddles Use Nylon plugs for masonry; metal anchors for concrete.

Phase 2: Earthing & Bonding System

Critical for: Personnel Safety, Noise Reduction, Surge Protection.
Item Specification Details Application
Main Earth Bar 40x5mm Copper Busbar, 12-Hole w/ Disconnect Link Main bonding point in Electrical Room.
Bonding Conductors 25x3mm Copper Tape / Strip Perimeter grounding for racks and tray continuity.
Earth Cable (Main) 50mm² Cu, Green/Yellow, LSZH Main feed from Earth Pit to Room Busbar.
Earth Cable (Rack) 16mm² Cu, Green/Yellow, LSZH Bonding individual racks to the mesh/bar.
Insulation 8mm Epoxy/DMC Insulators & Studs Isolate earth bars from the wall/structure.

Phase 3: Power Distribution (Electrical)

Configuration: 3-Phase Input, Single Phase Rack Distribution.
Item Specification Details Quantity Estimation Logic
Rack PDU Legrand 24-Way Vertical (Zero-U), C13 Outlets 2 per rack (A+B Feed) recommended. Verify C19 need.
Main Power Cable 1 Core 50mm² (Red, Yellow, Blue, Black) Main incomer leads. LSZH Insulation.
Distribution Cable 4 Core 16mm² Flexible Copper Feeds to individual Rack Junction Boxes.
Junction Boxes IP65 Polycarbonate, DIN Rail, Terminals 1 box per rack group. 1-in-5-out config.
Terminations Cu Lugs/Thimbles (Pin, Ring, U-Type) Advance Tip: Order Long-Barrel lugs for better contact.
Safety Heat Shrink Sleeves (R/Y/B/Bk/G) Mandatory at all termination points.

Phase 4: Structured Cabling (Fiber & Copper)

Strict Color Coding: See Governance Section Below.
Item Sub-Type Advanced Spec
Fiber Backbone Outdoor Cable 24-Core MM (OM4 recommended), Armored, Loose Tube.
Fiber Panels LIU / ODF 24-Port LC Duplex, Sliding drawer type.
Fiber Cords Patch Cords LC-LC Duplex. Must match mode (OM3/OM4).
Copper Panels Patch Panel 24-Port CAT6, Loaded, 110-IDC Punch down.
Copper Cable Bulk Cable CAT6 U/UTP, 23 AWG, LSZH Jacket.
Cable Mgmt Rack Managers 1U Brush Panels (for air seal) & 1U Horizontal Managers.

Phase 5: IT Hardware & Accessories

Final Fit-out.
Item Details Purpose
Storage Kingston 960GB / 1TB SSD (SATA/NVMe) Server boot drives or local backup.
Optics SFP Transceivers 1G LX (1310nm) Note: LX is typically Single Mode. Verify if SX (Multimode) is needed for OM4.
Rack Airflow 1U Blanking Panels Crucial: Install in all empty rack U-space to prevent heat recirculation.
Labeling Cartridge Tapes (12mm/18mm) 12mm for patch panels, 18mm for cable wrapping.

Phase 6: Fire Stopping & Penetration Sealing

Mandatory for compliance with fire codes.
Item Specification Details Application Area
Intumescent Pillows Fire-rated expansion pillows (2hr rating) For filling voids in trunking/trays passing through walls.
Fire Sealant Acrylic Intumescent Mastic Sealing small gaps around conduits.
Fire Foam PU Fire Rated Foam (Pink) For sealing large irregular gaps in masonry.
Warning Labels “Fire Stop Sealed” Stickers To be placed next to every sealed penetration.

Phase 7: Installation Consumables & Tools

Item Details Usage
Velcro Ties 10mm/20mm Roll (Black/Blue) Strictly NO plastic zip ties on CAT6/Fiber.
Fiber Cleaning Isopropyl Alcohol (99%) & Wipes Essential for cleaning fiber tips before plugging in.
M6 Hardware Heavy Duty Cage Nuts & Screws (Black) Extra packs (budget +20% for dropped nuts).
Electrical Tape Vinyl Tape (Phase Colors) For marking cable ends and looming power cables.
Ferrules Bootlace Ferrules (0.5mm – 2.5mm) For terminating stranded wires in DIN terminals.

Phase 8: Monitoring & Environmental Sensors

Item Specification Details Application
Temp/Humidity Sensors Networked (SNMP) Digital Probes Top, Middle, Bottom placement in critical racks.
Leak Detection Rope Conductive Fluid Sensing Cable Perimeter of AC units and under raised floors.
Smoke Detectors VESDA Systems Integrated with building Fire Alarm Control Panel.

Phase 9: Rack Containment & Airflow Mgmt

Item Specification Details Installation Notes
Side Air Baffles Steel/Plastic Vertical Sealing Strips Prevent air bypass between rails and panels.
Floor Grommets Brush-type Sealing Grommets Seal floor cutouts where cables enter/exit.
Cable Chimneys Vertical Exhaust Ducts Direct hot exhaust air to the ceiling plenum.

Phase 10: Safety, Signage & Site ID

Item Specification Details Compliance
Safety Signage Photoluminescent “Exit” / “Electrical Hazard” ISO 7010 Standard.
Cable ID Tags Stainless Steel / Rigid PVC Tags Durable tags for 50sqmm main feeders.
Floor Grid ID A-Z / 1-9 Coordinate Floor Stickers Matches DCIM coordinate system.

Project Governance & Standards

1. Color Coding Schema (Strict Adherence)

  • Red: LAN 2 (Critical / Redundancy)
  • Blue: Cyber-Security / OOB
  • Green: General LAN / Access
  • Yellow: CCTV / Physical Security
  • Grey/Black: Voice / Telephony
  • Purple: AV / Media
  • Orange: SAN / iSCSI Storage

2. Testing Requirements (Deliverables)

  1. Copper: Fluke DSX Certification for every node. Pass criteria: TIA Cat6 Perm Link.
  2. Fiber: OTDR Trace for outdoor; LSPM loss test for patch cords.
  3. Earth: Pit resistance test report (< 1.0 Ohm) + Continuity test.
  4. Environmental: Sensor calibration report for probes.

3. Documentation Handover

  • As-Built Drawings: CAD layout showing exact paths and numbering.
  • Port Matrix: Excel mapping Patch Panel -> Switch -> Floor Location.
  • Warranty: 20/25-Year System Warranty from OEM.
  • Safety Manual: Evacuation paths and EPO instructions.

4. Missing Quantities to Verify (RFQ Prep)

Total length of 300mm Tray (Calculate linear meters + 15% waste).
Count of “Drops” (Data points) to calculate Bulk Cable boxes.
Number of Racks to calculate Cage Nuts (Approx 50 per rack).
Count of Wall/Floor Penetrations (for Fire Stopping estimation).
Count of Floor Tiles to be cut (for Grommet estimation).
