Computer Hardware: Perform Essential Functions and Concept

Computer Hardware: Perform Essential Functions and Concept
Computer Hardware Design & Assembly Guide

Computer Hardware Design & Assembly

Professional reference for PCB design, components, assembly, testing & troubleshooting

PCB Layout & Design Fundamentals

Design Layers

  • Top Layer – Primary components & signals
  • Ground Plane – EMI shielding & return paths
  • Power Plane – Voltage distribution
  • Bottom Layer – Secondary routing & SMD
TOP LAYERGROUND PLANEPOWER PLANEBOTTOM LAYERVia
⚠ Critical Design Rules:
Trace width ≥0.15mm for 1A • Via size ≥0.3mm • Clearance ≥0.1mm • Separate digital/analog ground

Component Identification & Specs

Passive Components

Resistors, Capacitors, Inductors

Tolerance
±1% to ±5%
Package
0603-1206
🔌

Active Components

Transistors, ICs, Diodes

Frequency
MHz to GHz
Power
mW range
🖥

Connectors

Power, Signal, Data

Standards
USB, SATA, PCIe
Rating
5A @ 5V+

Assembly Process & Workflow

1PCB Prep2Paste3Pick Place4Reflow

REFLOW PROFILE

Preheat: 160-180°C / 60-90s
Soak: 180-200°C / 60-120s
Peak: 240-260°C / 10-30s
Cool: 6°C/sec to room

QUALITY CHECKS

✓ Visual Inspection
✓ AOI Automation
✓ X-Ray Scan
✓ Functional Test

Troubleshooting Guide

Cold Solder Joint
Dull, grainy. Cause: Low temp. Solution: Reflow or hand-solder
Solder Bridge
Unwanted connection. Solution: Solder wick or desoldering
Tombstoning
Component on one end. Solution: Reflow adjustment
No Power
Check: Voltage, caps, regulator, fuse with multimeter

Latest Technology

🔬

AI Accelerators

Neural processors for ML

Performance
100+ TFLOPS
Process
5nm

Power Delivery

Advanced VRM

Phases
16+
Efficiency
97%+
🌡

Thermal

Liquid cooling

Dissipation
500W+
Efficiency
TDP -10°C

Top Brands

SEMICONDUCTORS

IntelAMDNVIDIAQualcommARMTSMCSamsung

MANUFACTURING

FoxconnFlexSanminaWistronCompal

COMPONENTS

MurataTDKYageoKemetVishay

Implementation Examples

Signal Integrity

  • Matched impedance 50Ω
  • Differential spacing ≤ 3x
  • Ground under traces
  • Via stitching 10mm
  • Length match ±10mm

Power Integrity

  • Bulk caps near VDD
  • 0.1µF per IC pin
  • 100nF decoupling
  • Star-point grounding
  • Separate planes

Thermal

  • Thermal vias 0.5mm
  • Copper ≥ 1cm²
  • Mask removed
  • Heatsink paste
  • PCB 1.6mm min

EMI Mitigation

  • Ferrite beads
  • EMI LC filter
  • Shielded zones
  • Via stitching
  • Twisted pairs
